                    Torque Sensor for Belt Pulleys







           Torque Sensor for Belt Pulleys




          Dieser Sensor hat eine berührungslose und digitale Signalübertragung von Rotor zu Stator, also ohne

Signalverf?lschung und wartungsfrei.

Nominal (rated) torques 50 N.m,

100 N.m, 200 N.m, 500 N.m,

1 kN.m, 2 kN.m, 3 kN.m, 5 kN.m

and 10 kN.m









          24-hour national online service:

                    025-84363968




















			Rated capacity


			±50 N?m ~ ±3 kN?m






			Safe overload


			150 %R.C.






			Ultimate overload


			300 %R.C.






			Rated output


			0 V ~ ±10 V0 V ~ ±5 V  4-20mA   5-15kHz   485  CAN






			Accuracy of detected value


			Digital : ±0.5 %R.O., Analog : ±0.25%R.O.±0.1%R.O.

(including linearity, hysteresis and repeatablity.)






			Maximum rotation speed


			RK-700100NM ~ -300NM : 5 000 rpm

RK-700-500NM, -1KNM :4000 rpm

RK-700-2KNM, -3KNM : 35 00 rpm






			Temp. range, safe


			-10 ℃ ~ 70 ℃






			Temp. range, compensated


			0 ℃ ~ 60 ℃






			Temp. effect on zero balance


			0.02 %R.O./10 ℃






			Temp. effect on output


			0.03 %LOAD/10 ℃






			Zero shift by rotation


			0.5 %R.O.p-p (at WB＝1 kHz)






			Mechanical characteristics


			100NM


			200NM


			300NM


			500NM


			1kNM


			2KNM


			3KNM









			Torsional peculiar pitch (kHz)


			5.357


			5.778


			6.577


			6.413


			6.274


			4.040


			4.508









			Bending peculiar pitch









			Radial direction (kHz)


			3.375


			3.497


			3.763


			3.919


			4.016


			2.151


			2.368









			Thrust direction (kHz)


			3.966


			4.065


			4.284


			4.404


			4.988


			2.672


			2.844









			Twist angle at rated capacity (°)


			0.015


			0.027


			0.031


			0.037


			0.049


			0.067


			0.082









			Accuracy safe bending

load (N)


			75


			150


			225


			375


			750


			800


			1 000









			Accuracy safe thrust

load (N)


			65


			130


			195


			325


			650


			3 750


			12 000









			Class of protection


			IP54






			Material


			Rotor part : Alloy steel, Stator part : Alluminium alloy
